KH-50 50L Mixing Granulator

Kontex KH-50 Food and Pharmaceutical Mixing Granulator 50L
kontex intensive mixer ,pelletizer,Granulator,It can be used in many industries such as food, medicine, foundry sand, refractory materials, metallurgy, pelletizing, environmental protection, compound fertilizer, lithium battery, ceramics, and catalysts.

Kontex – Clean Mixing & Granulation for Food, Pharma & Feed Additives

Clean Series – redesigned for strict hygiene.

• Quick-release parts for easy disassembly• Smooth surfaces, obstruction-free – fast cleaning• Web-based PLC control with data logging

One machine, multiple processes – mixing, de-agglomeration, dispersion, granulation, coating, drying – all in one unit. Replaces multiple lab machines, saves space and cost.

EFFECTIVE CLEANING

Optimized accessibility, smooth surfaces, and selected components ensure effective, repeatable cleaning.

EXTRA FLEXIBILITY

Quickly switch between processes by changing mixing tools and adjusting parameters.

ERGONOMIC & EASY OPERATION

Product-contact parts (tools, disc, scraper, bowl) can be assembled and disassembled in seconds.

Technical Features – Kontex Mixing & Granulating Machine for Food & Pharma

Working volume: 1 – 2000 L
Integrated mixing & granulation tools (optional)
Various bowl geometries; tool speed adjustable from 0.6 to 40 m/s
Removable mixing bowl for ergonomic access and easy cleaning; wall scraper prevents material buildup
All stainless steel, surface finish RA < 0.8 μm
Excellent scalability for future upgrades

Specialized Applications

From gentle to intense de-agglomeration mixing, depending on tool speed and type.
Shear force adjustable to control particle properties (size distribution, density) – granulation from 50 μm fines up to 5 mm pellets.
Jacket temperature control for heating – ideal for melt granulation or temperature-sensitive products.
Kneading and subsequent suspension with excellent material circulation; both steps ensure complete de-agglomeration.

Kontex KH series mixer-granulator integrates mixing, granulation, drying, sizing, and coating in one closed sanitary system – designed for food, feed additives, and pharmaceuticals. Full stainless steel with mirror-polished, dead-corner-free finish meets GMP and food safety standards; optional CIP available. PLC/HMI precisely controls speed, temperature, spray, etc.; handles heat-sensitive ingredients (low-temp granulation) and potent APIs (fully sealed containment), while optimizing particle shape to mask taste. Compared to conventional equipment: binder usage -25%, productivity +4~5x, energy consumption -35%~-55%. From lab to production scale with full data traceability.

Equipment Exhibition
